The Orbea Rise H30 is your gateway into Orbea's "Rider Synergy" all day adventures.

The aluminium framed H30's power, like its carbon siblings,  comes from an EP8 RS motor, developed in an exclusive collaboration between Shimano and Orbea.
Orbea re-engineered the motor's firmware to bring about the most efficient and naturally realistic power assistance possible. They've managed to eliminate the drag and power delay that’s typical of conventional e-bikes with this motor that's optimized to provide maximum assistance between 75 and 95 strokes per minute, replicating the power that you'd expect  at the cadence at which the human body pedals most efficiently and effectively. If you're the type of rider who would normally roll around all day on turbo boost, then this might not be the bike for you, but if you;'re a discerning stylish rider who wants a nimble mountain bike that can ride for further, then you're looking in the right place with the Orbea Rise H30

Click on these Orbea Rise H30 deals to see more:

Releated Deals:Orbea Gain eBikeOrbea Rise H10Orbea Rise H15Orbea Rise M-LTDOrbea Rise M-TeamOrbea Rise M10Orbea Rise M20Orbea Wild H10Orbea Wild H20Orbea Wild H30Orbea Wild M-LTDOrbea Wild M-TeamOrbea Wild M10Orbea Wild M20

About the Orbea Rise H30


The two most distinguishing features of Rise are its natural pedalling and handling feel. Orbea's engineering team scrutinised every detail and invested many hours in development to maintain these characteristics in the aluminium versions.

Orbea rethought the distribution of the 21,700 cells and their set-up,  to find a battery that is as lightweight as possible, with one of the highest energy densities available in a mountain bike.

Orbea used its polishing process on the frame to give the new aluminium version the most attention possible. This technique smooths the welds at the tube joints, making them look like they belong on a carbon frame. In fact, distinguishing between an aluminium frame and a carbon frame is difficult. This process also improves the fatigue resistance of aluminium in critical areas.

Incidentally, Orbea chose the best materials and used the most advanced manufacturing processes for the frame, just as it does for its highest-level carbon frames. The team optimised the thickness and shapes of the tubes and reinforced the most delicate areas by using double and triple butted tubes, to save weight where it is unnecessary and add in stiffness where it is you really want it.

All of this design and development work has resulted in an aluminium frame weight of 3.4kg — just 100g more than an regular aluminium frame and 2kg lighter than the majority of aluminium e-bikes on the market. The new aluminium Rise weighs an impressive 19kg for the top-of-the-line model and 20kg for the entry-level model. If you're looking for an epic electric mountain bike at an affordable price, then this is it.


Orbea Rise H30 Specifications


FRAME: Orbea Rise Hydro 2022 140mm travel 29" Boost 12x148

SHOCK: Fox Float DPS Performance 3-Position Evol custom tune 210x55mm FORK Marzocchi Bomber Z2 140 QR15x110 Fox 34 Float Performance 140 3-Position QR15x110

CHAINRING: e*thirteen e*spec Direct Mount 32T Boost CRANK e*thirteen Plus Alu HEADSET Acros Alloy 1-1/8 - 1-1/2" Integrated HANDLEBAR OC1 35mm 12mm Rise 780mm

STEM: OC1 3D Forged 35mm interface 7o SHIFTERS Shimano Deore M6100

BRAKES: Shimano MT410 Hydraulic Disc ROTORS 180mm Front /180mm Rear 203mm Front /180mm Rear

CASSETTE: Shimano CS-M7100 10-51t 12-Speed

REAR DERAILLEUR: Shimano SLX M7100 SGS Shadow Plus CHAIN Shimano M6100

WHEELS: Race Face AR 30c Tubeless Ready

TYRES: Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR

TYRES: Maxxis Rekon 2.40" 120 TPI 3CMaxxTerra Exo+ TLR

SEATPOST: OC Mountail Control MC20, 31.6mm, Dropper OC MC20 Mountain Control Dropper, 31,6mm, 125mm travel OC MC20 Mountain Control Dropper, 31,6mm, 150mm travel

SADDLE: Fizik Taiga S-alloy rail Fizik Taiga Kium rail

MOTOR: Shimano EP8-RS

BATTERY: Orbea Internal 540Wh (Optional 252Wh Range Extender)
