Van Rysel E-EDR

The Van Rysel E-EDR sets out to answer a specific question: how much help can you add to a road bike before it stops feeling like one? The answer across the current UK range is a discreet rear-hub motor, an integrated battery and conventional drop-bar road equipment. The target rider is the roadie who wants to smooth out long climbs, extend weekend loops and keep up with a quicker group, without moving to the look and bulk of a utility e-bike.

What is the latest Van Rysel E-EDR?

The newest and most capable current UK platform is the E-EDR CF Shimano 105 Di2. This is the carbon bike with the Mahle X20 system, a 350 Wh integrated battery, 55 Nm of assistance and an official UK RRP of £3,799.99. Alongside it sit two current aluminium AF builds: the E-EDR AF Shimano 105 Di2 at £3,199.99 and the E-EDR AF Apex AXS at £1,999.99. The naming matters because the AF is not simply a cheaper groupset option. It uses a different frame material, a different Mahle motor generation, a smaller battery, different tyres and more practical luggage mounts.

Van Rysel does not attach an official model year to the current range. Retailer year labels matter less than the build name, and any older listing with mechanical Shimano 105 2x11 belongs in a separate group rather than the current electronic builds.

E-EDR CF and AF frames, fit and likely road character

Both platforms are rigid, so the comfort story comes from endurance-road geometry, tyre volume and your own fit rather than suspension. The published CF chart runs from XS to XL, growing taller and slightly longer through the sizes, while handlebar width, stem length and seatpost length step up with each frame. A moderate 418 mm chainstay is shared across every CF size, and the size-specific cockpit should keep handling planted without drifting into upright-hybrid territory.

Wheel and tyre choice underlines the split. The carbon bike comes with 700x28 tyres and a 32 mm frame limit, so there is a little room to fit a plusher 30 mm or 32 mm road tyre for rough lanes. Both AF builds start on 700x32 tyres and accept up to 35 mm, while also carrying rack and fork mounts. That makes the aluminium bikes the more natural base for light touring or everyday practical rides, even though they give away weight and battery capacity. The published weight is 12 kg for the CF, while each AF build is under 14 kg in size M.

Assistance is pedal-driven on every build and stops at 25 km/h. Above that threshold you are riding a normal road bike with extra mass. Van Rysel states the X20 produces no noticeable braking resistance when the motor is inactive, and the CF's published 12 kg figure should make unassisted sections far more manageable than on a heavy full-power e-bike. Nico Petit-Braquet's review for Le Blog du Cycliste found the CF's low-level support smooth on steep climbing and described the bike behaving like a carbon endurance road bike once it was rolling above the assistance threshold. Expect that same boundary on the aluminium X35 builds, just with less push.

The CF page also publishes a maximum load of 100 kg. Add up rider, clothing, spares and any luggage before you settle on a size.

Van Rysel E-EDR CF vs E-EDR AF builds

The E-EDR CF Shimano 105 Di2 is the performance-led package. Its carbon frame, full-carbon fork, 350 Wh battery and 55 Nm Mahle X20 rear-hub motor are matched to Shimano 105 Di2 2x12 with a 50/34 chainset and 11-34 cassette. Braking comes from Shimano 105 hydraulic discs with 160 mm rotors at both ends. That adds up to the family's strongest climbing package and its most road-like unassisted feel. The optional 171 Wh range extender is not supplied as standard, and fitting one takes up one of the two bottle positions.

The E-EDR AF Shimano 105 Di2 keeps the same electronic 2x12 shifting and hydraulic stoppers but moves to an aluminium frame, a 250 Wh non-removable battery and the gentler 40 Nm Mahle X35 motor. Stock tyres grow to 700x32, clearance reaches 35 mm, and the frame and fork mounts open the door to a compatible rack or light fork luggage. This is the build for someone who wants Di2 refinement and practical capacity more than the lightest possible package.

The E-EDR AF Apex AXS is the entry point and the most distinctive setup. It retains the same aluminium X35 platform but swaps to wireless SRAM Apex XPLR AXS 1x12 with a 42T chainring and an 11-44 cassette. There is no front derailleur to think about, and the range still covers varied gradients. The trade is cadence: the steps between gears are wider than on the 2x Shimano builds, which you will notice more when you are trying to hold a precise rhythm on rolling roads. If simple operation matters more than close ratios, this is the natural choice.

Van Rysel publishes maximum range figures for planning, not promises: up to 150 km from the CF's 350 Wh battery, up to 200 km with the X20 extender, and up to 100 km for the AF builds. Hills, headwinds, assistance level, luggage, temperature and tyre pressure will all move that figure. Treat it as a route-planning guide and recharge before the big ride.

UK weather, charging, punctures and maintenance

The integrated batteries are designed to be charged on the bike, not carried to the kitchen. On the AF builds the battery is non-removable, and even the CF's battery is not a routine removal item. That makes charging access the first ownership question. If your storage is a flat, a shared stairwell or a locked shed without power, plan where the bike will live before you commit.

Range extenders are available for both systems, but the X20 and X35 accessories are not interchangeable, so match the extender to the platform. The practicality trade is also real: they cost extra, add weight and, on the CF, use a bottle-cage position. The use case is a very long or very hilly day rather than ordinary commuting.

Wet UK rides are supported, but the electrical components should not be immersed or pressure-washed. A normal wipe-down after mucky rides and regular chain care during winter will do more for the bike than anything else, and hydraulic brakes deserve a periodic check. Van Rysel covers the bikes with a standard 2-year warranty, with AF battery support quoted at 2 years or 500 charge cycles.

Puncture practice is worth a dry run at home rather than discovering the process in the rain. The motor lives in the rear wheel, so removal involves the electrical connection and a little more care than a conventional quick-release road wheel. Carry the correct tool for the actual axle before your first long ride. The wheels and tyres are tubeless-ready, which gives you the option of running tubeless, but compatible equipment is not a promise that the bike leaves the box already set up that way.

How the earlier E-EDR AF 105 2x11 build differs

Some UK listings still show an earlier E-EDR AF Shimano 105 2x11 build. It sits on the same aluminium Mahle X35 platform, but uses mechanical shifting rather than the current Di2 or AXS electronic options. A listing for an E-EDR AF 105 without Di2 in the name is likely that older build, not one of the current electronic models, which is the main thing to untangle before comparing offers.
